品牌:荏源
起订:1台
供应:100台
| 品牌 : | 荏源 | 是否进口 : | 否 |
| 产地 : | 日本 | 加工定制 : | 否 |
| 型号 : | EBARAA70W | 电源电压 : | 380V |
| 用途 : | 抽真空 | 尺寸 : | 334*224*667cm |
无锡荏源EBARA A70W 扬州荏源真空泵维修 嘉兴荏源真空泵维修 杭州真空泵维修
EBARA真空泵系列包括：
EBARA A07V， EBARA A10W，EBARA A25，EBARA A30W，EBARA A70W
EBARA AA10 ，EBARA AA30，EBARA AA40，EBARA AA70 ，EBARA AA100，EBARA AAS70
EBARA-A07V，EBARA A10S，EBARA A25S
EBARA 40X20
等
EBARA 40X20,EBARA 50X20,EBARA 65X40,EBARA 80X25,EBARA 1540X40
EBARA A07V,EBARA A10S,EBARA A25S,EBARA A30W,EBARA A70W,EBARA A150W
EBARA AA10,EBARA AA20 ,EBARA AA30 ,EBARA AA40,EBARA AA70,EBARA AA100,EBARA AA200
EBARA AAS10N,EBARA 20N,EBARA AAS40N,EBARA AA70N,EBARA AA 100,EBARA AA 200,EBARA AA 300WN
EBARA A70W Multi-Stage Dry Vacuum Pump - REBUILT
Technical Characteristics
Complete pump safeguard system
High pump operating temperature preventing condensation
Low noise and low vibration
Corrosion resistant materials-stainless steel coolers, water circuits
High reliability even for harsh processes
Efficient interstage coolers for LPCVD nitride process
Canned motor
Low service requirements
Control panel for monitoring operating conditions
Customer Benefits
Very low nitrogen consumption for purging
Clean room compatible
Low service requirements
Compact size and small footprint
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Pumping speed (N2) 50/60 Hz | 7,000 / 8,400 l/min |
| Pumping speed (N2) 50/60 Hz | 420 / 504 m3/h |
| Ultimate pressure 50/60 Hz | 3 x 10-3 / 1.3 x 10-3 mbar |
| Ultimate pressure 50/60 Hz | 0.3 / 0.13 Pa |
| Water consumption | 3.5 l/min |
| Nitrogen consumption | 14-16 slm |
| Nitrogen consumption | 24-27 Pa m3/sec |
| Voltages ranges | 200-220/380-415 V |
| Motor power, installed | 2.2+3.7 kW |
| Weight, approx. | 380 kg |
| Dimensions | 825 x 400 x 760 mm |
| Inlet flange size | DN 50 KF |
| Outlet flange size | DN 40 KF |
