| 阀瓣开启高度 : | 微启式安全阀 | 公称通径 : | 6（mm） |
| 品牌 : | REGO | 3C阀门类别 : | 工业 |
| 连接形式 : | 螺纹 | 材质 : | 黄铜 |
| 型号 : | PRV9432TP | 结构形式 : | 杠杆式 |
| 加工定制 : | 否 | 适用介质 : | LNG |
LNG安全阀REGO PRV9432TP
进口LNG超低温安全阀
Style Size Inlet A Body and Valve Material Pressure Setting Range PSIG Height B Wrenching Hex C Orifice Size Sq. Inch Pipe-Away Adapter P/N Pipe-Away Outlet F.N.P.T.
PRV 9432 1.4” Brass 17-600 2.6 7.8” .062 B-9412-2 3.8”
SS 9432 1.4” Stainless Steel 17-600 2.6 7.8” .062 SS-9412-4 1.2”
PRV 9433 3.8” Brass 17-600 2.6 7.8” .062 B-9412-2 3.8”
SS 9433 3.8” Stainless Steel 17-600 2.6 7.8” .062 SS-9412-4 1.2”
PRV 9434 1.2” Brass 17-600 2.8 7.8” .062 B-9412-4 1.2”
SS 9434 1.2” Stainless Steel 17-600 2.8 7.8” .062 B-9412-4 1.2”
B- 9425 3.4” Brass 50-300 3.4 13.4” .43 B-3131-10 1”
B- 9426 1” Brass 100-300 5.5 23.8” .62 B-3132-10 11.4”
Division of Engineered Controls International, Inc. Division of Engineered Controls International, Inc. Division of Engineered Controls International, Inc.
Models Inlet Height Wrenching Hex Orifice
A B C Size
PRV 19432 and PRV29432 1/4” 2.6” 7/8” .062 sq. inch
PRV 19433 and PRV29433 3/8” 2.6” 7/8” .062 sq. inch
PRV 19434 and PRV29434 1/2” 2.8” 7/8” .062 sq. inch
Part Number Pressure Setting (PSI) Flow Capacity (SCFM/Air) Inlet Connection (M.NPT) Height A Wrenching Hex B
UA3149A303 303 9,805* 21.2” 101.2” 41.8”
UA3149A330 330 10,188*
UA3149A358 358 11,601*
Part Number Thread Conections Dim. A Dim. B Dim. C
CAP750 3/4”Female NPT 1.250” 1.313” 1.313”
CAP1000 1”Female NPT 1,500” 1.750” 1.750”
CAP1500 1 1/2”Female NPT 1.750” 2.375” 2.375”
CAP2000 2”Female NPT 2.000 3.250” 3.250”
B-19434B Series
C-19434B Series
Application
The B-19434B Series relief valves are suitable for use with
oxygen and non corrosive gases.
The C-19434B series relief valves are designed for use in
carbon dioxide service.
Features
.
Both designs permit the valve to open slightly to relieve moderately excessive pressure.
.
When the pressure increases beyond a predetermined point, the valve opens to its full discharge capacity in order to quickly reduce excess pressure.
.
Pipe-away adapter for venting gas to the outdoors is available.
.
A.S.M.E. rated. NB Certified.
.
B-19434-B Series are cleaned for use in oxygen per CGA G-4.1.
Materials
Body.............................................................................Brass
Spring .............................................................Stainless Steel
Seat Retainer................................................................Brass
Seat Disc (B-19434B Series) ............................Fluorosilicone
(C-19434B Series)............EPDM Synthetic Rubber
Pipe-Away Adapter.......................................................Brass
Ordering Information
Part Number Pressure Setting (PSIG) ASME Relief Capacity (CFM/Air) Height A Width B Inlet Connec-tion (M.NPT) C Pipe-Away Adapter Part Number D
B-19434B235 235 476 215.16" 13.4” 1.2” *B-19434-5 1.2” F.NPT Outlet
B-19434B250 250 505
B-19434B300 300 601
B-19434B350 350 691
B-19434B375 375 736
C-19434B235 235 476
C-19434B250 250 505
C-19434B280 280 555
C-19434B300 300 601
C-19434B350 350 691
C-19434B375 375 736
* Pipe Away Adapter is sold separately. ** Contact factory for additional settings.
Division of Engineered Controls International, Inc.
